VMC - Eurorack MIDI Modules

VMC stands for "Versatile / Voltagecontrolled / Variable - MIDI - Companion / Cruncher / Controller / ..." - choose what you want.


Picture of the pre-series module. From left to right: simple in/out/thru-module, VMC-1 main module, triple in/thru module, triple out module.

The VMC-System is a series of modules for Eurorack systems, which provide MIDI handling within a modular eurorack system. The modules are internally connected by an additional ribbon cable, which provides a +5V owersupply, MIDI busses and an analog clock bus.
Basically this bus can be combined with the Fluxus Modules by http://soundcomplete.net/ if an adapter board is used.

The modules are distributed under the brand name fanwander .

At the moment the following modules are available:
VMC-1

The VMC-1 is a generic module, which combines an ARDUINO NANO with a display, five buttons, three digital-inputs and two control voltage inputs with amount control.
This module may run various software.

At the moment I offer two sequencer programs (SQ-3P. SQ-4M), a Chord-Trigger and VelocityModifier, and a MasterClock generator. Many more may follow.

You need at least one of the Input/Output modules listed below to connect the VMC-1 to youre MIDI-environment. For details see the VMC-1 users manual
  • Width: 18HP
  • Depth: 40mm
  • Price (assembled module): 190,- Euros (excl. VAT)

Buy it here

for pricing of kits and parts see below

VMC-2 (Not yet available - planned fo 04/2024)

VMC-2 can read up to 8 analogue signals (voltage or gate/trigger) and control or produce MIDI events according to these input signals.

For each input signal there is an attenuator.

The software is not finalized yet. The main purpose of the first beta version is to send MIDI-events on triggers and / or to serve as a voltage-to-MIDI converter. A first draft of the manual for the software is available at https://www.florian-anwander.de/cv2midi/.

VMC-2 requires an input/output module (see below: MIDI-ITO[s] or MIDI-3IT/MIDI-OOO)

  • Width: 10HP
  • Depth: 40mm
  • There is no pricing available yet; we assume betwen 140 and 180 Euros.


The right picture shows a preseries module
CLOCKMAN

ClockMan is a generator for MIDI clock, DIN-Sync and the clock for the VMC bus.

I also serves as an editor tool for the ClockBoy modules.

ClockMan provides both clock signals on the 5 pole DIN socket. It does not require an input/output module as long as you don't want to insert the clock into the MIDI signal coming from your master keyboard.

  • Width: 10HP
  • Depth: 40mm
  • Price (assembled module): 140,- Euros (excl. VAT)
Buy it here

for pricing see below

The picture shows a preseries version, with some manual wiring, The final version won't have those wires .
CLOCKBOY

ClockBoy is a flexible tool for clock handling.
  • ClockBoy reads either MIDI clock, DIN-Sync or the clock from the VMC bus.
  • ClockBoy converts the incoming clock into the corresponding other clocks and into clock-triggers for analogue sequencers and similar devices.
  • ClockBoy generates signals for sequencer control, like start, stop, reset, run-gate, and bar-start.
  • ClockBoy can shuffle the clock-trigger (for even time signatures only).
  • ClockBoy provides a pause- / restart-function for all outgoing clock signals. The pause function works for various bar lengths of 4/4 time, as well as for 3/4, 5/4 and 7/8 time signatures. I give big kudos to John Pillans, who invented this function, and developed the wonderful Mungo-Enterprises Sync2.
  • ClockBoy can be configured using the start- and stop-buttons or by MIDI control change data coming either from an external MIDI source or from the ClockMan (see above).
ClockBoy provides the outgoing clock signals for DIN-Sync and MIDI on the 5 pole DIN socket.

ClockBoy is available in two variations of the frontpanel. The "skiff version" (shown in the pictures) provides the sockets at the rear position. So the start / stop buttons are not hidden by cables. The "rack version" (no picture available yet - sorry) provides the sockets at the lower position, so the cables don't hang over the start / stop buttons.

To read MIDI-clock from another source than a ClockMan a MIDI input/output module is required. The connection to ClockMan is achieved by the VMC bus. To read DIN-Sync the built in DIN socket is used

  • Width: 8HP
  • Depth: 40mm
  • Price (assembled module): 140,- Euros (excl. VAT)

Buy it here

for pricing see below

The picture shows a preseries version. The final version will have minor changes only.
MIDI-ITO

A simple module, which provides MIDI input, output and thru. The module is connected with a bus cable to the VMC.
  • Width: 6HP
  • Depth: 40mm
  • Price (assembled module): 80,- Euros (excl. VAT)


Buy it here

for pricing see below


MIDI-3IT

A module with MIDI input and thru; the input can be routed to three different busses. So it is possible to control up to three VMCs or similar modules from one MIDI source without the necessity to switch the MIDI channel on the keyboard. Controlling multiple busses at the same time is possible too.
  • Width: 6HP
  • Depth: 40mm
  • Price (assembled module): 80,- Euros (excl. VAT)

Buy it here

for pricing see below


The picture shows a prototype with some test wiring, the old name and simple mounting holes! The dimensions for the regular module are the same
MIDI-OOO

A module with three separate MIDI out sockets, for the three possible busses of this system.
  • Width: 6HP
  • Depth: 40mm
  • Price (assembled module): 70,- Euros (excl. VAT)
Buy it here
for pricing see below


MIDI-ITOs

Same as MIDI-ITO, but only with 3.5mm sockets. Due to the mountingposition of the multipin connector it is deeper than the other modules.

Width: 2HP
Depth: 45mm



manufactured on demand only
for pricing see below


MIDI-INV

A simple passive module, which converts from the official pin assignement according to MIDI specification, which is used by Korg, MakeNoise and the VMC-System, to the non-standard pin assignement used by Arturia and Novation.

Width: 2HP
Depth: 25mm

manufactured on demand only
for pricing see below




VMC-1 and the MIDI-xxx-moduls are available as assembled modules and as kits. Frontpanels and PCBs may be sold separately. CLOCKMAN and CLOCKBOY will be available only assembled for the first run.

How to buy:

To order please use the ORDER PAGE . I don't accept orders on other communication channels (phone, messenger services, private or public messages in forums...). Orders are valid only if they are confirmed by me in written form (email or letter).

Price List:

Module Kit Complete Panel PCB
VMC-1 130,- 190,- 35,- 15,-
CLOCKMAN
100 ,-
140,-
30,-
15,-
CLOCKBOY
100,-
140,-
30,-
15,-
MIDI-ITO 50,- 80,- 25,- 10,-
MIDI-3IT 50,- 80,- 25,- 10,-
MIDI-OOO 45,- 70,- 25,- 10,-
MIDI-ITOs (*) 45,- 70,- 15,- 10,-
MIDI-INV (*) 30,- 60,- 15,- 08,-

(*)MIDI-ITOs and MIDI-INV are produced only on demand - for requests please send an email

All prices in Euros without VAT (ohne Mehrwertsteuer), without shipping.
If the buyer is in the European Union and cannot provide a VAT-ID, I have to bill the VAT that is valid in the buyers country.
If the buyer is not in Germany but in the European Union and has a VAT-ID registered on his name, the prices are without VAT.
Buyers outside the European Union don't have to pay VAT. But keep in mind that you will have to pay your local taxes and customs fees.

Documents:

Various downloads

  • eagle_libraries.zip . I use some slightly modified libraries for eagle:
    • ArduinoNanoV30_lgdDrills.lbr: the original library uses small drills for the pins, which do not fit standard pinheaders -> I changed the diameter of the drills
    • PJ3410_sockets.lbr: all libraries for the PJ3410 I found had the milling for the pins at the wrong position -> I corrected this
    • lcd_dem16216.lbr: -> removed two mounting holes, that I do not want to have on the VMC-1 board; also I moved the origin marker of the display to the center
    • con-hirschmann_nognd.lbr: the MIDI-3IT and the MIDI-OOO use a version of the MAB5SV socket without ground pin -> I removed the ground pin
    • con-hirschmann_gnd2normal.lbr: the MIDI-ITO uses a version of the MAB5SV socket with ground pin not defined as power pin
  • download this zip-file and unpack it
  • copy the five files from the resulting folder to the libraries folder of your eagle installation
  • enter "use *" in the command line in eagle to reload the libraries.

Licenses

All modules are Open Hardware under the condition of creative commons license "cc by-nc-sa 4.0".
All software is Open Software under the condition of creative commons license "cc by-sa 4.0".
Software derived from Emilie Gillets MIDI-Pal will be under the condition of GPL.
Sourcecodes like files for the pcbs and the frontpanels will be published here and github.
The files were created with eagle 6.6.0 and can be handled in the free version of eagle.

Availability

  • PCBs and panels are usually in stock. If I run out of stock, it takes around two to three weeks to produce new pcbs or panels.
  • Kits usually are available. If I run out of parts it takes around one week to reorder. For pcbs and panels see above.
  • The 2HP modules MIDI-ITOs and MIDI-INV will be produced only on demand. Delivery time will be up to four weeks depending on the suppliers for the panels and pcbs.
  • Complete modules are stocked only to a certain number. Sometime they have to be assembled on demand. Usually it takes one week to complete an order (I have a 40hour/week dayjob too)
  • I ship once a week (usually on wednesday). I ship with assured and tracked parcels by DHL (this is german postal services - don't mismatch with DHL international). This will be delivered usually with your national postal services. For shipping rates please check https://www.dhl.de/en/privatkunden/pakete-versenden/weltweit-versenden/preise-international.html
  • For packaging I reuse material that came in. I think this is the most ecological way to avoid waste.
